Building Your First RAG Pipeline: A Step-by-Step Tutorial

mkdir rag-tutorial && cd rag-tutorial
npm init -y
npm install @anthropic-ai/sdk openai @supabase/supabase-js
npm install -D typescript @types/node ts-node

ANTHROPIC_API_KEY=sk-ant-...
OPENAI_API_KEY=sk-...
SUPABASE_URL=https://xxx.supabase.co
SUPABASE_SERVICE_ROLE_KEY=eyJ...

-- Enable pgvector
create extension if not exists vector;

-- Documents table
create table documents (
  id uuid primary key default gen_random_uuid(),
  content text not null,
  metadata jsonb default '{}',
  embedding vector(1536), -- OpenAI text-embedding-3-small
  created_at timestamptz default now()
);

-- Create index for fast similarity search
create index on documents
  using ivfflat (embedding vector_cosine_ops)
  with (lists = 100);

-- Similarity search function
create or replace function match_documents(
  query_embedding vector(1536),
  match_threshold float default 0.7,
  match_count int default 5
)
returns table (
  id uuid,
  content text,
  metadata jsonb,
  similarity float
)
language sql stable
as $$
  select
    id,
    content,
    metadata,
    1 - (embedding <=> query_embedding) as similarity
  from documents
  where 1 - (embedding <=> query_embedding) > match_threshold
  order by embedding <=> query_embedding
  limit match_count;
$$;

interface Chunk {
  content: string;
  metadata: {
    source: string;
    chunkIndex: number;
    totalChunks: number;
  };
}

function chunkDocument(
  text: string,
  source: string,
  chunkSize = 500,
  overlap = 50
): Chunk[] {
  const chunks: Chunk[] = [];
  const sentences = text.split(/(?<=[.!?])\s+/);

  let currentChunk = '';
  let chunkIndex = 0;

  for (const sentence of sentences) {
    if ((currentChunk + sentence).length > chunkSize && currentChunk) {
      chunks.push({
        content: currentChunk.trim(),
        metadata: { source, chunkIndex, totalChunks: 0 }
      });

      // Overlap: keep last part of chunk
      const words = currentChunk.split(' ');
      currentChunk = words.slice(-overlap).join(' ') + ' ' + sentence;
      chunkIndex++;
    } else {
      currentChunk += (currentChunk ? ' ' : '') + sentence;
    }
  }

  if (currentChunk.trim()) {
    chunks.push({
      content: currentChunk.trim(),
      metadata: { source, chunkIndex, totalChunks: 0 }
    });
  }

  // Update totalChunks
  chunks.forEach(chunk => {
    chunk.metadata.totalChunks = chunks.length;
  });

  return chunks;
}

import OpenAI from 'openai';

const openai = new OpenAI();

async function generateEmbedding(text: string): Promise<number[]> {
  const response = await openai.embeddings.create({
    model: 'text-embedding-3-small',
    input: text.replace(/\n/g, ' '),
  });
  return response.data[0].embedding;
}

async function generateEmbeddingsBatch(
  texts: string[]
): Promise<number[][]> {
  const response = await openai.embeddings.create({
    model: 'text-embedding-3-small',
    input: texts.map(t => t.replace(/\n/g, ' ')),
  });
  return response.data.map(item => item.embedding);
}

import { createClient } from '@supabase/supabase-js';

const supabase = createClient(
  process.env.SUPABASE_URL!,
  process.env.SUPABASE_SERVICE_ROLE_KEY!
);

async function indexDocument(
  text: string,
  source: string
): Promise<void> {
  console.log(`Indexing: ${source}`);

  const chunks = chunkDocument(text, source);
  console.log(`Created ${chunks.length} chunks`);

  // Generate embeddings in batch (more efficient)
  const contents = chunks.map(c => c.content);
  const embeddings = await generateEmbeddingsBatch(contents);

  // Insert into Supabase
  const rows = chunks.map((chunk, i) => ({
    content: chunk.content,
    metadata: chunk.metadata,
    embedding: embeddings[i],
  }));

  const { error } = await supabase
    .from('documents')
    .insert(rows);

  if (error) throw error;
  console.log(`Indexed ${chunks.length} chunks from ${source}`);
}

interface RetrievedDocument {
  id: string;
  content: string;
  metadata: Record<string, unknown>;
  similarity: number;
}

async function retrieveRelevantDocs(
  query: string,
  threshold = 0.7,
  limit = 5
): Promise<RetrievedDocument[]> {
  const queryEmbedding = await generateEmbedding(query);

  const { data, error } = await supabase.rpc('match_documents', {
    query_embedding: queryEmbedding,
    match_threshold: threshold,
    match_count: limit,
  });

  if (error) throw error;
  return data || [];
}

import Anthropic from '@anthropic-ai/sdk';

const anthropic = new Anthropic();

async function answerQuestion(
  question: string
): Promise<{ answer: string; sources: string[] }> {
  // Retrieve relevant context
  const docs = await retrieveRelevantDocs(question);

  if (docs.length === 0) {
    return {
      answer: "I don't have enough relevant information to answer that question.",
      sources: []
    };
  }

  // Build context from retrieved docs
  const context = docs
    .map((doc, i) => `[Source ${i + 1}: ${doc.metadata.source}]\n${doc.content}`)
    .join('\n\n---\n\n');

  // Generate answer with Claude
  const response = await anthropic.messages.create({
    model: 'claude-opus-4-5',
    max_tokens: 2048,
    system: `You are a helpful assistant that answers questions based on provided context.

Rules:
- Only use information from the provided context
- If the context doesn't contain the answer, say so explicitly
- Cite your sources using [Source N] notation
- Be concise and accurate`,
    messages: [{
      role: 'user',
      content: `Context:
${context}

Question: ${question}`
    }]
  });

  const answer = response.content[0].type === 'text'
    ? response.content[0].text
    : '';

  const sources = [...new Set(docs.map(d => d.metadata.source as string))];

  return { answer, sources };
}

async function main() {
  // Index some sample documents
  const docs = [
    {
      text: `DevForge Academy offers 40+ programming tutorials covering web development,
             data science, and AI. Courses include HTML, CSS, JavaScript, Python, SQL,
             React, and our exclusive AI development curriculum.`,
      source: 'about.txt'
    },
    {
      text: `Our AI development courses cover prompt engineering, the Claude API,
             RAG pipelines, vector databases, AI agents, and deploying AI apps.
             These are DevForge exclusive courses not found elsewhere.`,
      source: 'ai-courses.txt'
    }
  ];

  for (const doc of docs) {
    await indexDocument(doc.text, doc.source);
  }

  // Query
  const result = await answerQuestion(
    "What AI topics does DevForge Academy cover?"
  );

  console.log('Answer:', result.answer);
  console.log('Sources:', result.sources);
}

main().catch(console.error);

-- Postgres full-text search + vector search
SELECT *, ts_rank(to_tsvector(content), plainto_tsquery($1)) as text_rank,
  1 - (embedding <=> $2) as vector_rank
FROM documents
WHERE to_tsvector(content) @@ plainto_tsquery($1)
   OR 1 - (embedding <=> $2) > 0.7
ORDER BY (0.3 * text_rank + 0.7 * vector_rank) DESC
LIMIT 10;

const expandedQuery = await expandQuery(userQuery);
// "RAG" → "Retrieval-Augmented Generation, vector search, document retrieval"
const docs = await retrieveRelevantDocs(expandedQuery);

const docs = await retrieveRelevantDocs(query, {
  filter: { source: 'documentation', date: { gte: '2024-01-01' } }
});
